Ethernet Profinet Kab Kalite B Pou Aplikasyon Kominikasyon
Estrikti pwodwi yo
Kondiktè: Thined Copper Kondiktè 4 * 22 awg / 7
Izolasyon: PE
Koulè: Blan ble jòn zoranj
Inner Jacket: PVC
1.Shield: AL / Mylar
2.Shield: Tinned Copper
Eksteryè Jacket: 6.5MM PVC
Koulè: vèt (menm jan ak RAL6018)
Pèfòmans elektrik
Frekans | RL | Atténuation | Next | PSNEXT | Faz reta |
(MHz) | (dB) | (dB/100m) | (dB) | (dB) | ns/100m Max |
1 | 2.4 | 20 | 65.3 | 62.3 | 570 |
4 | 4.9 | 23 | 56.3 | 53.3 | 552 |
8 | 6.9 | .24.5 | 51.8 | 48.8 | 546.7 |
10 | 7.8 | 25.0 | 50.3 | 47.3 | 545.4 |
16 | 9.9 | 25 | 47.2 | 44.2 | 543 |
20 | 11.1 | 25 | 45.8 | 43.8 | 543 |
25 | 12.5 | 24.2 | 44.3 | 41.3 | 541.2 |
31.25 | 14.1 | 23.3 | 42.9 | 39.9 | 540.4 |
62.5 | 20.4 | 20.7 | 38.4 | 35.4 | 538.6 |
100 | 26.4 | 19.0 | 35.3 | 32.3 | 536.6 |
Estanda
ISO/IEC 11801:2011; IEC61156-5:2009 ; EN50173; EN50288; TIA-568-C2:2009
Paramèt teknik
Tanperati opere: - 40 degre a 80 degre
Tanperati enstalasyon -20 degre a 60 degre
Rezistans flanm dife FT2VW-1
Tensile pèfòmans nan kab la: Max.50N
Tès kraze nan kab Max.3000N a
Min. Reyon koube: Fiks: 4D (dyamèt kab)
Mouvman okazyonèl: 8D (kab dyamèt)
Rezistans lwil oliv (IRM902): 70 degre * 4h (EN50290-2-22)
UV rezistans: UL1581section1200
Aplikasyon
Yo itilize li nan yon pakèt aplikasyon endistriyèl Ethernet, tankou fil elektrik machin, ekipman, enstriman ak kabinèt kontwòl, ak pèfòmans li konfòme ak CAT5e Apwopriye pou aplikasyon fleksib fleksib oswa aplikasyon detanzantan mobil. Li aplikab pou aplikasyon pwotokòl kominikasyon Ethernet endistriyèl tankou Ether CAT ak Ether Net/IP Profinet
